Yudian AI-508 digital temperature controller with thermocouple

FOB Reference Price:Get Latest Price
$24.20 - $44.50 / Units | 1 Unit/Units (Min. Order)
Usage:
Industrial
Theory:
Temperature Controller
Accuracy:
0.3%FS±5°C
Temperature range:
0~9999
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Fujian, China
Brand Name:
YUDIAN
Model Number:
AI-508
OUTPUT:
RELAY or SSR
Color:
Grey or Black
Operating Ambient:
-10℃ to 60℃ ; ≤90%RH
Power supply:
100-240VAC/ 50Hz; 120-240VDC
Product name:
temperature controller with thermocouple
Supply Ability
Supply Ability:
2000 Unit/Units per Day
Packaging & Delivery
Packaging Details
Standard Carton boxes with Yudian logo
Port
XIAMEN port
Video Description





Yudian AI-508 digital temperature controller with thermocouple

___________________________________________________________________________



   I. Technical Specification:



1. Input type : K,T, E, J, N, PT100

2. output type: Relay, SSR voltage output.

3. Accuracy : 0.3%FS±2°C

4. Resolution : 1℃

5. Control mode: On-off control or PID control

6. Alarm function: High Alarm, Lower limit alarm,Deviation High Alarm.

7. Power supply voltage rating: 100-240VAC, -15%, +10% / 50-60Hz or 24VDC

8. Ambient temperature: -10~+60°C, Humidity: 0~90RH%

___________________________________________________________________________



   II. Front panel and Operation:







___________________________________________________________________________



   III. Model Code:







The type of AI-508 is made up of 4 parts:







                                           AI-508     A    G   L0



                                               1         2     3     4



Part 1:



      AI-508 digital temperature controller, accurancy  0.3%FS±2°C







Part 2: Dimension



      A: 96*96mm



      D: 72*72mm



      D2: 48*48mm



      E: 48*96mm



      F: 96*48mm







 Part  3:Output Type



     G: SSR voltage output, capacity  30mA/5VDC



     L: Relay contract output, capacity 2A/250VAC



     K1:Single zero crossing trigger output (100-380VAC, can trigger thyristor 5-500A)



     K3: Triple zero crossing trigger output (100-380VAC)







 Part 4:  Alarm



     N: No alarm.



     L0:  1 alarm



     L3:  2 alarm



___________________________________________________________________________



   IV. AI-508 digital temperature controller Installation and wiring:





                                   ( Wiring graph for A,E,F size )









                                   ( Wiring graph for D size )









                                  ( Wiring graph for D2 size )









___________________________________________________________________________





You will get



Other Products



Why choose Yudian?

1)Factory with 25 years experience.

2)Quick delivery ( within 3~5 working days).

3)Retail/Wholesale/OEM/ODM available .

    We expect to cooperate with machinery manufacturers, better price for bulk order.

4)We provide after sales service and technical assistance as per the customers requirement and needs.









FAQ

1. How long will you give me the reply?

we will contact you in 2 hours as soon as possible
2. Could I get samples of controller?
Yes,we have products in stock ,so you can get the samples quickly.
3. How about the quality of our products?
We have the certification of ISO,CE and ROSH,we could send the certification test of our company to you.
4. Could I visit your factory?
Of course,if you need we will help you to visit our factory.
5. If I have paid,when will you help me to produce?
We will start producing immediately after receiving the payment.
