YUDIAN industrial automation digital temperature controller

FOB Reference Price:Get Latest Price
$50.00 - $100.00 / Piece | 1 Piece/Pieces (Min. Order)
Usage:
Industrial
Theory:
Temperature Controller
Accuracy:
0.25
Temperature range:
0-9999
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Fujian, China
Brand Name:
YUDIAN
Model Number:
AI-518
Color:
Grey or Black
Precision:
0.25%FS ± 0.1℃
Size:
96*96,160*80,80*160,72*72,48*48,48*96,96*48
Modularization Design:
Customization
Power Consumption:
Less than 6W
Packaging:
Standard Export Package
Power supply:
100~240VAC, -15%, +10% / 50-60Hz; 120~240VDC; or 24VDC/AC, -15%, +10%.
Delivery Detail:
temperature controller
Resolution:
0.1°C for K, E, T, N, J, Cu50, Pt100; 1°C for S, R
Approval:
CE,UL
Supply Ability
Supply Ability:
4000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
Standard packing for export
Port
xiamen /HK

 Digital Industrial Process Digital Temperature Controller YUDIAN AI-518

__-02_-03

PRODUCT DESCRIPTION

519 key point518 details_plus



Ideal for accurate controls of temperature, pressure, flow, level, humidity etc



Aslo, we can supply OEM service for you, changing to your assigned logo and color.



1. Main features:



AI-518 High measurement accuracy: 0.25%FS ± 0.1°C

PID, auto tuning, ON/OFF

Universal programmable input

Universal input power- 85-264VAC, or 11-26VAC/VDC

Highly versatile Output, multiple modules available

Wide variety of alarm mode selectable

CE, RoHS, ISO9001 approved



2. Specification:



Control mode

On-off control mode
AI PID Control with Auto Tuning(AT)

Measurement

accuracy

0.25%FS ± 0.1°C

Resolution

0.01°C

Response time

≤0.3s ( when digital filter parameter dL=0)

Input

Thermocouple: K, S, R, T, E, J, N,WRe3~WRe25,WRe5~WRe26 etc

Resistance temperature detector: Pt100, Cu50

Linear voltage:0~5V,1~5V,0~1V,0~100Mv, 0~20mV, 0~500Mv etc

Linear Current:0~10Ma,0~20mA,4~20mA

Input range

Thermocouple: K(-100~1300°C), S(0~1700°C), R(0~1700°C),

 T(-200~+390°C), E(0~1000°C), J(0~1200°C),B(600~1800°C),

 N(0~1300°C)

Resistance temperature detector:Pt100(-200~+800°C) , Cu50(-50~+150°C)

Output

(modularized)

Relay output (NO+NC): 250VAC/2A or 30VDC/1A

TRIAC Switch Output

TRIAC zero Crossing trigger output

SSR Voltage output: 12VDC/30mA (used to drive SSR)

Linear current output: 0~20mA, 4~20mA (The output voltage of X module ≥10.5V;

and that of X3 module ≥10.5V.)

General specifications

Voltage: support AC85-265V,50/60Hz or DC24V.

Power consumption: ≤3W

Electromagnetic compatibility (EMC) : ±4KV/5KHz according to IEC61000-4-4;

4KV according to IEC61000-4-5.

Operating Ambient : temperature -10~60°C; humidity ≤90%RH
